DFO Flood Event 4470

Quebec, Canada May 7, 2017

Overview Flood Map

Layers, bottom to top: Red is flooding mapped from ESA Sentinel 1a SAR data. Blue is "permanent" water. Urban areas (satellite-visible lights) are shown in dark gray.

Geotif version



Image samples: Change detection September 9, 2016/May 7, 2017 image pair subscene.



Explanation

Event Reporting:

The Flood Observatory maintains a Global Active Archive of large flood events, 1985 to present. This listing is available to the public in both spreadsheet and GIS formats (both formats together provide the complete Archive). New events are entered into this archive each week. As of the end of 2016, there were 4432 events; each has a unique archive number. A single GIS polygon for each event defines in approximate terms the total area affected.

Event Mapping:

In some cases, severe or damaging floods become the focus of Observatory inundation mapping. As part of collaborations with other organizations, and the Global Flood Partnership, the Observatory's maps and other data are made available to the public. With attribution, they can be used freely, including for commercial purposes, under the terms of the Creative Commons license shown below. Geotif versions and GIS files are also provided for these maps through the links below.

This event is selected for Observatory production of map and GIS data products.This web page and associated image and map (GIS) files are the permanent Flood Observatory record of this event. As the flood event proceeds, additional flood extent layers are added; the objective is mapping of the maximum extent flooded.

This Event:

Provided here is brief information leading to the selection of this flood for mapping.

According to FloodList: "Canada – 100s Evacuate Floods in Quebec as More Heavy Rain Forecast 6 May, 2017 by Richard Davies in Americas, News · 0 Comment Update, 08 May 2017: A state of emergency was declared in Montreal on Sunday afternoon 07 May and will remain in place for 48 hours. In a statement, officials said: “On May 7, Montréal declared a state of emergency in three boroughs and two reconstituted cities within the agglomeration in response to an unprecedented rise in water levels causing flooding in the following areas: Ahuntsic–Cartierville; L’Île-Bizard–Sainte-Geneviève; Pierrefonds-Roxboro; Sainte-Anne-de-Bellevue; and Senneville. There remains a risk of flooding for various sectors on the Island of Montréal. A total of 179 homes have been evacuated.” Urgence Québec say that flooding across the province of Quebec has now affected 146 cities or municipalities, with 2,429 homes flooded, 1,520 people evacuated and 427 roads closed. As many as 1,200 troops have been deployed to help evacuate people and shore up flood defences, according to Canada’s National Defence. Original report, 06 May 2017: Further flooding has affected parts of Quebec, Canada after prolonged rain over the last few days. This is the second major flood event in the province in the space of 3 weeks. In mid April three municipalities declared a state of emergency after flooding from the overflowing Gatineau and Ottawa rivers. Meanwhile the wet weather continues and Environment Canada has warned of potentially heavy rain southeast of Lakes Erie and Ontario later today, and then Eastern Ontario into Quebec this weekend "

In addition to the maps above, for web map service-based information visit this DFO link. Zoom in to location of interest, and turn on appropriate event and other data layers.

Suggested citation:

Brakenridge, G.R. and Kettner, A. J., date accessed, "DFO Flood Event #", Dartmouth Flood Observatory, University of Colorado, Boulder, Colorado, USA, http address. Other citations to data incorporated in DFO maps are provided below.

Creative Commons License
The maps and web page are by G. R. Brakenridge and A. J. Kettner and are provided here under the terms of a Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License.

Image Data Sources:

NASA Landsat 8 and ESA Sentinel SAR data if used in this map were obtained from the the U.S. Geological Survey Hazards Data Distribution System. and the Sentinels Science Data hub, respectively. Landsat 8 is jointly managed by NASA and the United States Geological Survey.

Notes on Sentinel SAR data processing: Most commonly, two "exact repeat" images are retrieved from ESA's Sentinels Data hub, from before the flood and during the flood. ESA SNAP software is used to reproject the two images into a geographic (latitude and longitude) coordinate system. A 5x5 low pass filter is applied to both images. A threshold ranging from 50-60 is applied to the flood image, resulting in a subset of only very dark (interpreted as water) pixels. A threshold of .5-.7 is applied to a flood image/preflood image ratio product, resulting in a subset of pixels much darker in the flood image then before (this removes permanent surface water). A Boolean "AND" step then provides only pixels that satisfy both conditions.The exact thresholds used vary in the ranges provided; more strict thresholds map less flood water but also produce less false-positive errors. GIS vectors (polygons) are fit around pixels in the final "flood water" result: the red areas on the flood event maps, and the provided shp files.

GIS Data For These Maps:

Flood extent files (Shp or Mapinfo) supporting this Flood Event Map are located here.

These files may include high spatial resolution mapping such as from Sentinel or Landsat, or lower resolution files from MODIS. Draft versions may be posted and later revised; final versions include "final" in the file names. The WMS (web map server) also visualizes the final.shp files.

Click here for access to an automated daily MODIS-derived .shp file GIS record (record commences in 2011). Choose appropriate 10 deg x 10 deg map sheet directory and appropriate dates; longitude and latitudes refer to upper left map sheet corner. Not all floods are mappable at the MODIS spatial resolution of 250 m, Some DFO event maps also include these automated MODIS data.

Data from the Global Surface Water Explorer is included as part of the light gray previous satellite-mapped water extent. It is based on Landsat data at a spatial resolution of 30 m (Jean-Francois Pekel, Andrew Cottam, Noel Gorelick, Alan S. Belward, High-resolution mapping of global surface water and its long-term changes. Nature 540, 418-422, 2016). The NASA Shuttle Water Boundary Data (SWBD) surface water extent (90 m resolution), blue, was derived from NASA's the 11-day February, 2000, SRTM mission and this "permanent" water layer was also corrected using Landsat data.

When used, NASA NRT Global Flood Mapping maximum water extent for the years 2013-2015, at 250 m spatial resolution, provide part of the (light gray) previous satellite-mapped water extent layer. DFO creates these annual water extent layers from data provided by that project, by accumulating into one annual file all of the daily .shp files for each year. DFO has also produced flood extent files through mapping of individual floods (~ yr 2000 to present); these are also included in this layer.

Related Data:

The flood model layer represents a 6-year simulation (2006-2011) of flood inundation from the 2-D LISFLOOD-FP flood model and it shows the predicted maximum extent of flooding during that period. This is an estimate of where flood waters can reach during high magnitude events. The model was conditioned on event-continuous flows as simulated by the Water Balance Model (WBM), a large-scale hydrological model. The river network used in the 2-D flood model is based on Landsat, with rivers larger than 50 m in width being simulated, and the floodplain topography is from the globally available SRTM-DEM. The resulting accuracy of floodplain inundation is affected by how accurate the flow simulation and by any errors in SRTM-DEM topography. DFO combines this flood model layer with all previously mapped flooding to produce a flood hazard layer suitable for comparison with new flood events.

Global Flood Monitoring System (GFMS) displays, if provided here, are from the University of Maryland.  Reference: Wu, H., R. F. Adler, Y. Tian, G. J. Huffman, H. Li, and J. Wang (2014), Real-time global flood estimation using satellite-based precipitation and a coupled land surface and routing model, Water Resour. Res., 50, doi:10.1002/2013WR014710.

Global Flood Awareness System (GloFAS) displays, if provided, are from the European Commission Joint Research Centre and the European Centre for Medium-Range Weather Forecasts. Reference: Alfieri, L., Burek, P., Dutra, E., Krzeminski, B., Muraro, D., Thielen, J., and Pappenberger, F.: GloFAS – global ensemble streamflow forecasting and flood early warning, Hydrol. Earth Syst. Sci., 17, 1161-1175, doi:10.5194/hess-17-1161-2013, 2013.

Funding, Data and Institutional Support by (varies with event number):

NASA's Earth Sciences Program, the Latin American Development Bank, the World Bank, the European Commission (Global Disaster Alert and Coordination System, GDACS), the Google Earth Engine research awards program, the Committee on Earth Observation Satellites (CEOS) Disasters Working Group-Flood Pilot, the Japanese Space Agency, and the European Space Agency. GPM and AMSR-2 satellite microwave data for River Watch is processed first within GDACS.

The Dartmouth Flood Observatory was founded in 1993 at Dartmouth College, Hanover, NH USA and moved to the University of Colorado, INSTAAR, CSDMS in 2010. The institutional support of both universities is gratefully acknowledged.
