DFO Flood Event 4464

Argentina, March 6-April 19, 2017

International Charter Activation # 525

Flood Maps

Overview Map

Layers, bottom to top: Very light red is all previous satellite-mapped flooding, 2000-present. Red is flooding mapped from ESA SAR and NASA optical data. Blue is pre-flood surface water. Flooding is only depicted when it extends beyond this "normal" water extent. Urban areas (satellite visible lights) are shown in gray.

The red areas are based on the automated NASA Global Flood NRT processor (see below) and a 14 day accumulation ending on the date shown. Also included is Sentinel SAR information from a March 20/January 19, 2017 comparison.

Geotif version



Explanation

Event Reporting:

The Flood Observatory maintains a Global Active Archive of large flood events, 1985 to present. It is available to the public in both spreadsheet and GIS formats (both formats together provide the complete Archive). New events are entered into this archive each week. As of the end of 2016, there were 4432 events; each has a unique archive number.

Event Mapping:

In some cases, severe or damaging floods become the focus of Observatory inundation mapping. As part of collaborations with other organizations, and the Global Flood Partnership, the Observatory's maps and other data are made available to the public. With attribution, they can be used freely, including for commercial purposes, under the terms of the Creative Commons Attribution 3.0 Unported License. Geotif versions and GIS files are also provided for these maps through the links below. This event is selected for Observatory production of map and GIS data products.This web page and associated image and map (GIS) files are the permanent Flood Observatory record of this event.

This Event:

According to the International Charter for Space and Major Disasters, April 12, 2017, "Torrential rain has caused flooding in southern Argentina, forcing thousands of people to evacuate. The rain started at the end of March and has caused the Dulce and Chico Rivers to overflow, affecting cities in the area. One city which has particularly been affected is Comodoro Rivadavia. Estimates suggest that 80% of the city has been destroyed by floods and mudslides after the city received more than a year of rain in less than a week. Bridges and roads in the city were destroyed or disrupted and much of the city is flooded with mud and water. A yellow alert is also in place for the Río Hondo reservoir, located in northern Argentina, which is overflowing". This is Activation #525 for the Charter. The above flood maps are for flooding in northern Argentina, Santiago del Estero Province; DFO Event 4462 provides mapping for flooding in southern Argentina (also included in the Charter activation).

For a web map service version, visit this DFO link and, zoom in to location of interest, and turn on appropriate data layers.

Suggested citation for this Creative Commons-licensed publication:

Brakenridge, G.R., and Kettner, A. J., date accessed, "DFO Flood Event #", Dartmouth Flood Observatory, University of Colorado, Boulder, Colorado, USA, http address.

Image Data Sources:

NASA Landsat 8 and ESA Sentinel SAR data if used in this map were obtained from the the U.S. Geological Survey Hazards Data Distribution System. and the Sentinels Science Data hub, respectively. Landsat 8 is jointly managed by NASA and the United States Geological Survey. Flood modeling results if used are from the NASA/University of Maryland Global Flood Monitoring System (GFMS), Drs. Robert Adler and Huan Wu, University of Maryland/ESSIC.

GIS Data Sources:

Event-specific water extent files supporting this Flood Event Map are located here. These may include high spatial resolution mapping such as from Sentinel or Landsat, or lower resolution files from MODIS. Draft versions may be posted and later revised; such revisions will include in the file names "r1", "r2", etc. The older files remain in this folder but generally should not be used. Both MapInfo and Shp formats are provided.

Click here for access to the automated daily MODIS-derived .shp file GIS record (record commences in 2011).

(Choose appropriate 10 deg x 10 deg map sheet directory and appropriate dates; longitude and latitudes refer to upper left map sheet corner; not all floods are mappable at the MODIS spatial resolution of 250 m)

Data from the Global Surface Water Explorer (a download data link is provided) is included as part the (dark blue) surface water layer. It is based on Landsat data at a spatial resolution of 30 m (Jean-Francois Pekel, Andrew Cottam, Noel Gorelick, Alan S. Belward, High-resolution mapping of global surface water and its long-term changes. Nature 540, 418-422, 2016). On the map, it is shown together with the NASA Shuttle Water Boundary Data (SWBD) surface water extent (90 m resolution) processed from the 11-day February, 2000, SRTM mission and corrected using Landsat data. Large flood events are not normally depicted in either data set. Thus, red areas on our maps show flood extent beyond these more typical water extents.

When used, NASA NRT Global Flood Mapping maximum water extent for the years 2013-2015, at 250 m spatial resolution, provide part of the (dark blue) maximum flood mapped. DFO creates these annual water extent layers from data provided by that project, by accumulating into one annual file all of the daily .shp files for each year. DFO has also produced flood extent files through mapping of individual floods (~ yr 2000 to present); these are also included where available in this maximum flood extent layer.

Related Data:

Global Flood Monitoring System (GFMS) displays, if provided, are from the University of Maryland.  Reference: Wu, H., R. F. Adler, Y. Tian, G. J. Huffman, H. Li, and J. Wang (2014), Real-time global flood estimation using satellite-based precipitation and a coupled land surface and routing model, Water Resour. Res., 50, doi:10.1002/2013WR014710. Global Flood Awareness System (GloFAS) displays, if provided, are from the European Commission Joint Research Centre and the European Centre for Medium-Range Weather Forecasts. Reference: Alfieri, L., Burek, P., Dutra, E., Krzeminski, B., Muraro, D., Thielen, J., and Pappenberger, F.: GloFAS – global ensemble streamflow forecasting and flood early warning, Hydrol. Earth Syst. Sci., 17, 1161-1175, doi:10.5194/hess-17-1161-2013, 2013.

Funding, Data and Institutional Support have been provided by:

NASA's Earth Sciences Program, the Latin American Development Bank, the World Bank, the European Commission (Global Disaster Alert and Coordination System, GDACS), the Google Earth Engine research awards program, the Committee on Earth Observation Satellites (CEOS) Disasters Working Group-Flood Pilot, the Japanese Space Agency, and the European Space Agency. GPM and AMSR-2 satellite microwave data for River Watch is processed first within GDACS. The Dartmouth Flood Observatory was founded in 1993 at Dartmouth College, Hanover, NH USA and moved to the University of Colorado, INSTAAR, CSDMS in 2010. The institutional support of both universities is gratefully acknowledged.
